AMtech 1/48 P-40E Warhawk
by Scott Van Aken

HISTORY

The P-40 Warhawk was made famous by the Flying Tigers, a band of mercenary
pilots who fought for money and glory. Most of us don’t like to think
of these men as such, but it is the truth. They were allegedly paid
handsomely to fly and paid a $500 bonus for every plane shot down. Not
your standard operating policy in a military that at the time paid pilots
less than $100 a month. However, it did ingrain the P-40 into the minds
and fantasies of an air-minded public.

It was also the best aircraft in the USAAF inventory. Decidedly outmatched
at altitude against German planes, it was a match for them at lower
altitudes. Though not as maneuverable as the Japanese planes, it was
faster and able to take battle damage that the other could not. It was
with this aircraft that the US entered the war in the Pacific. Until
the advent of the P-38, it, along with a some P-39s, were all that were
available to fight the Army’s Pacific war.

Fortunately, this wasn’t a war of high altitude as in Europe, so the
sluggish performance of the P-40 and P-39 above 15,000 feet wasn’t a
real problem. Even when removed from the front lines, the P-40 soldiered
on in China, Burma and India as well as in the Southwest Pacific as
a fighter bomber, staying in action until almost the end of the war.

THE KIT

Well, I messed up and didn’t take any photos of the kit on the sprues.
However, if you have seen any of the AMT P-40 kits, then this one will
not be new to you. This is basically the kit that AMT never released.
AMT decided to get out of the airplane kit business in 1997/98 so halted
any additional work on upcoming models. With the take-over by Racing
Champions, these molds went into storage.

AMtech has made arrangements with Racing Champions to lease the molds
and produce several kits that AMT had scheduled. The P-40E is the first
of those kits, with several others in 1/72 to follow. The big benefit
to this kit is that you don’t have to kitbash the AMT P-40K and P-40F
kits to build an E. I did this last year to produce the P-40E and a
P-40L. A bonus is that you get the P-40K tail as well as different exhaust
and engine cowlings. P-40Es had at least two types of exhaust installed
so you need to have some sort of photo evidence to accurately do yours.

The kit itself is well molded. Absent on this one was the amount of
flash that was present in the AMT P-40s. However, it is the AMT mold,
so little else is changed. The sliding part of the canopy is still thicker
on one side than the other, the molding of the fuel tank and tailplane
edges are still ragged, and the detailing of the instrument panel is
still poor on the lower section. However, I’m sure that none of these
items are beyond the skills of the average modeler to either fix or
hide!

CONSTRUCTION

Construction
was started in the time honored way. Subassemblies. The seat was glued
to the armor plating and the plating glued to the cockpit floor. The
control stick was glued in place. Then the wings were glued together.
With the other two kits, I had real problems getting the engine covers
to fit. This time, it was only half as bad. One side fit well but the
other did not. Unlike previously, I matched up the very forward section
of the panel. This left the gap at the rear, which was then filled with
superglue. When dry, the part that jutted out was sanded down some to
get it close. Then the join was slathered with filler and smoothed out.
Lost detail was rescribed with an Xacto that has a broken tip. I find
this works just as well as anything else.

The interior bits and pieces were painted US Interior Green from Aeromaster,
while the wheel wells and other places were painted with Model Master
Chromate Green that had been darkened just a touch with black.

Returning to the wings, there are holes predrilled for under wing bomb
racks. As I mentioned in the previous P-40 review, I have only found
two pictures of these racks installed on a plane, and both were on very
late war P-40Ns used by the RAAF and RNZAF. You can fill these holes
with putty, but probably the best way to do it without having to sweat
filler shrinkage is to install the bomb racks, and when dry, cut them
off and sand smooth the little nubs that are left. Any tiny holes that
are there can be easily filled and sanded. That is what I did and it
works quite well. When dry, the gun barrels were drilled out and the
wings generally filled and cleaned up along the leading edge where I
had gouged some plastic.

Back to the
fuselage, the nose radiator inlet was glued in place, the prop shaft
trapped between the fuselage halves and the fuselage glued together.
This was not an easy task as I had several alignment holes that were
not open so the pins wouldn’t mate. Despite drilling them out again,
I must have been off as they were not a help so I removed the pins from
the other half. Once the fuselage was glued together, I took a look
at it. Now I want to reiterate that this is a test shot so you cannot
expect perfection. The most glaring areas were just behind the cockpit
where the section was slightly short shot, the anti-glare panel area
which seems to be further back on one side than the other, and an area
just at the back of the wing on the the underside, which was also short
shot. The last area is no concern as it is covered by the wing fairing
when it goes on.

The upper cockpit area was filled and sanded smooth as was the area
around the anti-glare panel. Actually, a section of that was built up
somewhat with filler and the part that juts into the cockpit will be
trimmed back. The sill where the windscreen/canopy will fit is in good
alignment and there will not be a problem there.

With the fuselage
together, there was the usual slathering on of filler to take care of
gaps, mostly on the bottom aft portion of the kit. Then the cockpit
was installed. Thankfully, the kit is designed to have this done from
the underside, so it just makes things so much easier. Next are the
tailplanes. One of mine did not have the upper section totally complete
and there was about a 1/16th ledge along the back section that will
need to be filled. Again, this is a test shot. This molding would be
rejected in a normal kit run. I found that if the stabilizers were to
be glued on as is, there would be a misalignment at the very front.
If you look at the image, you can see the unmodified stabilizer on the
right. At this point, what most modelers would do is to trim back a
touch on the mounting tongue at the front. This is what I did on the
left stabilizer and you can see the results on the left side of the
image. It gets it close, but it still isn’t spot on. The key to fixing
this is to trim the mounting tab and trim back a bit on the aft portion
of the fuselage mount (see the red circle). This completely cures the
problem, and I did that on both stabilizers.

With the stabilizers fixed, the interior was installed and when dry,
the wing glued in place. Fit is fair, but there were problems. First
of all the front fit very well and only a small amount of filler was
needed. Moving to the upper surface, the right wing fit quite well.
The left wing, however, had a step between it and the wing root. No
cure other than several filler applications and sanding. Moving to the
aft underside shows another problem. First I should mention that the
wing covers the short shot shown above so there is no need to fix that.
However, there is a gap at the back that MUST be filled. When confronted
with gaps of this size, filler won’t do it. It needs to be filled with
plastic first. I found that a strip of Evergreen .030 x .030 plastic
fit right in there with no trouble. The area was then securely glued
and when dry, sanded down flush. Smaller gaps were filled with filler
or thick paint.

Once the aft wing gap was smoothed out, the radiator flaps were glued
on. Fastidious modelers will undoubtedly want to find something to fill
in the large hole back there, for at the proper angle, you can see out
of it from the carb intake on the nose. AMT missed putting something
there to block this when the engineered the molds. Perhaps some enterprising
aftermarket maven will include a radiator exhaust area in a set.

Moving to the upper fuselage area, the cockpit got some final touch-ups
and then the windscreen and canopy were installed. True to its AMT roots,
the sliding hood is thicker on one side than the other, so most of you
will probably glue it shut or get an aftermarket vacuformed version.
Once attached, these items were masked. The plane I am modeling had
no radio mast, so that hole was filled and smoothed. The plane was now
ready for some paint.

PAINT & DECALS

Like many of you, this is my favourite part. I had initially decided
on doing a 49th FG Warhawk from New Guinea in 1942, however, I had just
received the latest copy of R/T from IPMS Canada, and this year they
had decided to send us all a decal sheet with Canadian WW2 aces aircraft.
In amongst the Spitfires was a lone Kittyhawk from the desert air forces,
and my choice switched to this plane. I sorta like desert schemes and
thought I’d add this one to the collection.

The underside was painted azure blue from the Aeromaster acrylic line.
When dry, the tailplanes were masked and the upper surface painted middlestone,
an Aeromaster enamel color. With aircraft of this size, I generally
freehand the camouflage. I know that the British used masks to do the
real planes, but I’m going to say that this one was repainted in the
field! It isn’t that far from true as often aircraft arrived with temperate
schemes and were repainted in desert colors before being issued to a
squadron. I had used up all my Aeromaster dark earth so went to Xtracolor
for that shade. The Xtracolor was thinned more than usual and the air
pressure turned way down for this job so I could get a respectably thin
line. Once done, the kit was returned to the workbench for more gluing.

CONSTRUCTION CONTINUES

At this time the masks were taken out of the wheel wells (which had
been painted a darkened Testors chromate green), and the area touched
up. The gear struts were painted neutral grey and glued in place as
was the tail wheel. Then the main wheels were glued on. The kit then
had a coat or two of clear gloss sprayed on it in anticipation of the
decals.

The IPMS Canada decals are superb and fit quite well. I used the weaker
Microscale setting solution and they went on beautifully. One thing
I did notice is that the white was slightly off register causing it
to peek out from under an edge of all the wing roundels. It also seemed
as if the wing decals were slightly oversized compared to the decal
placement sheet, though they matched the size callouts required by the
written instructions. Most odd.

This model represents an aircraft that was the mount of James ‘Stocky’
Edwards when he was with 94 Sq in 1941. Though no indication is given,
apparently he shot down no enemy aircraft flying the Kittyhawk with
this unit. He then transferred to 260 Sq where he shot down 15 1/2 aircraft.
He then went on to 92 Sq in Italy with Spit VIII’s and then to command
274 Sq. Prior to D-day, his unit moved back to England and in 1944 converted
to the Tempest. Late in the war he was made wing commander and replaced
Johnny Johnson as head of 127 wing. He ended the war with 16 victories
and stayed in the RCAF, retiring in 1969.

His Kittyhawk was a very bland aircraft with little to distinguish
it other than code letters. However, it has the early war fuselage and
underwing roundels that add some interest to it.

With the decals on and properly settled in, the model was given a cleanup
to remove any setting solution or glue that had dried on it. It was
then taken to get a coat of clear matte sprayed on it.

Returning from that sortie, the landing gear covers were glued in place
and any paint touched up. Then the prop was glued into the red-painted
spinner and that attached to the nose. The gun barrels were painted
gunmetal and the exhaust was given a few coats of RustAll after the
drilled out areas were filled with flat black paint.

At this time, the masking was removed from the plane and the radio
aerials attached using clear stretched sprue. Finally, the exhaust and
guns were given some stains using pastels and the kit was complete.

CONCLUSIONS

At last the 1/48 modeling world has an accurate P-40E without having
to resort to kitbashing or modifying existing kits. Why it took so long
to finally get one of accurate shape on the market is beyond me, but
it has happened. While it would have been nice to get an all-new kit,
the AMT version that AMtech is releasing is still a very nice kit with
no surprises. It has a few areas of concern as related above, but nothing
that is beyond the abilities of most modelers. I, for one, am quite
glad to see it finally hit the market and I’m sure that you will be
just as pleased with the kit once you have it in your collection.

Ed: I’d like to thank Scott, the web master of Modeling
Madness for the use of his article

© Scott Van Aken 2001
